pinch valves - pneumatically operated
pinch valve series PI08
directly operated; connection female thread; connection part stainless steel; tube natural rubber; control pressure 1,8...2,5 bar higher than effective operating pressure; medium temperature -10...+80 °C
pinch valve series VF
directly operated; body aluminum; aluminum flange with steel socket; tube natural rubber; control pressure 1,8...2,5 bar higher than effective pressure; medium temperature -10...+80 °C; flange DN40-DN150 PN10/16, DN200 PN10
pinch valve series PI03
NC; connection parts AISI 316L; tube NBR food-safe; medium temperature -20...+80°C
pinch valve series PI04
NO; connection parts AISI 316L; tube NBR food-safe; control pressure has to be adjusted acc. to diagram in data-sheet; medium temperature -20...+80°C
